The detecting part of the tile pressing machine includes: a pulse encoder for detecting the length of the color steel tile, a profiled up and down stroke switch, a cutter up and down stroke switch, a profiled up and down operation button, a cutter up and down stroke button, an emergency stop switch, and a hydraulic pressure Start and stop switches and so on.
The execution part of the tile pressing machine has a frequency converter drive motor, a hydraulic station motor, two hydraulic solenoid valves for the press type, and two hydraulic solenoid valves for the cutter.
PLC selects KDN-K306-24AR of KDN-K3 series. It has 14 inputs/10 relay outputs, which just meet the input and output requirements. With KDN text screen, parameter setting, alarm display, help information, production data display and so on can be completed.

The control system of the glazed tile pressing machine can also complete the veneer cutting function.
Characteristics of the control system:
1. The control system is simple to operate. Normal automatic production does not need to go back first, but advances once, presses the shape and the cutting is completed.
2. High precision, the cutting precision of each piece is less than 0.1mm, to meet the technological requirements.
3. The program runs stably and reliably.
