Foam composite board machine is a special production equipment for new building materials. Its main function is to composite color steel on thicker and lighter core material EPS (polystyrene/foam) board or rock wool board.
The foam composite board machine produces raw materials in the lower panel production area after rolling by pressing rollers, pressing out the convex surface, filling the core material in the filling area, and rolling in the upper panel production area by pressing rollers, pressing out the concave surface, which is opposite to the convex surface of the lower panel Correspondingly, after the upper and lower panels are combined with the sandwich layer to form a composite panel with grooves on both sides. The edge of the composite board cut along the center line of the groove is formed into a plug shape, and then a slot is opened on the other opposite side. When the board is connected to the board, the plug side is inserted into the slot side, so that the plug is more secure and overcome The problem of wall cracks caused by the direct seal connection is solved.

Foam composite board machine is the main equipment for producing color steel sandwich panel. Color steel sandwich panel is a new type of building material with high strength, light weight, strong durability and beautiful appearance. The foam composite board production line is easy to construct and has a short construction period. It is widely used in industrial plants, large supermarkets and warehouses, large-span roofs and walls, assembling various cold storages, purification rooms, air-conditioning rooms, etc.
The equipment of the foam composite board machine includes a lower panel production area, a core filling area, and an upper panel production area in order from the front to the rear of the conveying device. It is a round roller with a concave surface. The bottom roller of the pressure roller in the upper panel production area is a flat round roller, and the upper roller is a round roller with a convex surface.
